前几天不是入手了Miyoo mini嘛

想起之前坛子里有兄弟分享过看视频的功能

我就想着试试玩玩

但苦于不了解这个机器的性能，视频的分辨率（750×560），音视频的编码解码（H.264/H.265），码率。

还请大家赐教

更新：

The screen in the V4 is a different model and is using a resolution of 750×560 in comparison to the old 640×480

cpu资料-SigmaStar-SSD202D.pdf

MStar Word Template (sigmastarsemi.com)

ARM Cortex-A7 Dual Core up to 1.2GHz withNeon and FPU

H.264/H.265 FHD (1920x1080)@30fps Decoder

JPEG Encoder FHD (1920x1080)@15fps

 H.264/AVC Decoder

 Variable block size (16x16, 16x8, 8x16, 8x8, 8x4, 4x8 and 4x4)

 CABAC/CAVLC support

 Error detection, concealment and error resilience tools

 Supports max. resolution 4M (2688x1520) or 4-channel FHD (1920x1080) with 30fps decode

 H.265/HEVC Decoder

 I/P/B slices

− All intra-prediction modes

− All inter-prediction modes

 Variable CTU size: 64x64 to 16x16

− Variable Prediction Unit (PU) size: 64x64 to 4x4

− Variable Transform Unit (TU) size: 32x32 to 4x4

 High performance CABAC decoding

 Sample Adaptive Offset (SAO)

 Robust error concealment

 Supports max. resolution 4M (2688x1520) or 4-channel FHD (1920x1080) with 30fps decode

Audio Processor

 One mono ADC for microphone input

 Two stereo DMIC inputs

 One stereo DAC for lineout

 Supports 8K/16K/32K/48KHz sampling rate audio recording

 ADC Pre-Amp gain supports 0dB, 6dB, 13dB, 23dB, 30dB, and 36dB

 ADC boost gain supports -6dB ~ 15dB or 0dB ~ 21dB with interval 3dB

 ADC digital gain supports -63.5dB ~ 33dB with interval 0.5dB, can be muted to zero

 SNR of DR A-Weighted ADC > 90dB (@gain = 0dB)
